SPECIFICATIONS
OrientationLandscape only
High Definition LED DisplayHigh Brightness LED Panel - 700 Nits
Resolution1980 x 1024 (1080p)
Contrast Ratio4,000:1
Power RequirementsAC 120V, 60 Hz
Television Weight (without Speaker Bar)79 lbs.
Mounting Pattern350mm x 350mm
Warranty - Parts and Labor90 Day
Power Consumption120W without speaker bar140W with 20 watt speaker bar
Television Dimensions51-13/32"W x 30-1/2"H x 6-13/36"D with Soundbar)
Front of TV to Mounting Point6"
Television Weight (with Speaker Bar)94 lbs.
INPUTS
Ant / CableF type analog (VHF/UHF/CATV) (Digital Air / Cable)
ComponentComponent In (R/L, Pr(Cr), PA(Cb), Y
USBPhoto / Music Mode
Audio OutAudio out (3.5mm jack)Coaxial SPDIF Audio Out
HDMI 1HDMI
HDMI 2HDMI (MHL)
HDMI 3HDMI
AV InVideo (Y), Audio L (W), Audio R (R)
VGA/PC InAnalog RGB (PC) In (15pin mini D-sub female connector)
ADDED FEATURES
Partial Sun Cooling System ECB2Keeps the unit cool and dry in temperatures up to 140 degrees F (with power supplied)
Partial Sun Controlled Heater ECB2Protects TV from temperatures as low a -24 degrees F(with power supplied)
Innovative Water-tight Cable Entry SystemPass-through design keeps cables dry and allows for easy hook-ups (able to be locked)
Weatherproof Remote ControlIncluded with every TV purchase
Anti-Glare/UV Coated ScreensIncreases contrast and protects the LED screen from the sun‘s harmful rays
* All dimensions shown are for planning purposes only. We reserve the right to change materials and specifications without notice.
