SPECIFICATIONS
OrientationLandscape only
High Definition LED DisplayHigh Brightness LED Panel - 2,000 Nits
Resolution3840 x 2160 (4K UHD)
Contrast Ratio3,000:1
Power RequirementsAC 120V, 60 Hz
Television Weight (without Speaker Bar)33 LBS
Speaker Bar Weight6 LBS
Mounting Pattern325mm x 325mm
Television Dimensions30 5/16in W x 18 5/16in H x 6 7/16in D (21 5/16in H with Soundbar)
Front of TV to Mounting Point2-15/16"
Power Consumption120W without speaker bar120W with 20 watt speaker bar
INPUTS
ComponentComponent In (R/L, Pr(Cr), PA(Cb), Y
USBPhoto / Music Mode
Audio OutAudio out (3.5mm jack)Coaxial SPDIF Audio Out
HDMI 1HDMI
HDMI 2HDMI
HDMI 3HDMI
AV InVideo (Y), Audio L (W), Audio R (R)
VGA/PC InAnalog RGB (PC) In (15pin mini D-sub female connector)
ADDED FEATURES
Full Sun Cooling System ECB3Keeps the unit cool and dry in temperatures up to 140 degrees F (with power supplied)
Full Sun Controlled Heater ECB3Protects TV from temperatures as low a -24 degrees F(with power supplied)
Innovative Water-tight Cable Entry SystemPass-through design keeps cables dry and allows for easy hook-ups (able to be locked)
Weatherproof Remote ControlIncluded with every TV purchase
Anti-Glare/UV Coated ScreensIncreases contrast and protects the LED screen from the sun's harmful rays
* All dimensions shown are for planning purposes only. We reserve the right to change materials and specifications without notice.
